Description
LOCTITE IND406 is a tough 3D printing resin with high impact resistance that performs well in applications requiring high elongation & very high optical clarity.
This resin is so clear that it can be used to make indicator lenses & covers.
It maintains this high clarity outdoors without yellowing, which is a common issue with consumer grade resins.
Its high surface finish & elongation also makes it perfect for snap fit housings & casings on consumer goods.
Ideal for a wide variety of tools in the production floor, manufacturing aids & jigs.
Key Benefits:
- Toughest Clear resin without yellowing
- Elongation at Break – 96%
- Tensile Stress at Break – 38 MPa
- Young’s Modulus – 1400 MPa
- Shore Hardness – 76D
Biocompatibility: ISO 10993 -5/-23 passed
Color: Clear
Technical Specifications:
| Property |
Measure |
Method |
Value |
| Mechanical Properties |
| Young’s Modulus |
MPa |
ASTM D638 |
1,429 ± 52 |
| Tensile Stress at Yield |
MPa |
ASTM D638 |
42 ± 1 |
| Elongation at Yield |
% |
ASTM D638 |
5.0 ± 0.3 |
| Tensile Stress at Break |
MPa |
ASTM D638 |
35 ± 3 |
| Elongation at Break |
% |
ASTM D638 |
96 ± 4 |
| Poisson’s Ratio |
– |
ASTM D638 |
0.42 ± 0.05 |
| Flexural Modulus |
MPa |
ASTM D790 |
1287 ± 57 |
| IZOD Impact (Notched) |
J/m |
ASTM D256 |
72 ± 2 |
| Shore Hardness (3s) |
D |
ASTM D2240 |
76 |
| Other Properties |
| HDT at 0.455 MPa |
°C |
ASTM D648 |
53 |
| HDT at 1.82 MPa |
°C |
ASTM D648 |
46 |
| Water Absorption (24hr) |
% |
Internal |
0.9 |
| Solid Density |
g/cm³ |
ASTM D1475 |
1.134 |
| Thermal Conductivity |
W/(m·K) |
ASTM D5930 |
0.18 |
| Heat Capacity |
J/(g·K) |
ASTM D5930 |
0.91 ± 0.11 |
| CTE (-30°C to 45°C) |
µm/(m·K) |
ASTM E831 |
91.14 |
| Tg |
°C |
ASTM E1640 |
101.2 |
| Horizontal Burning Test |
– |
UL94 |
HB |
| Biocompatibility |
| Cytotoxicity |
– |
ISO10993-5 |
Comply |
| Irritation |
– |
ISO10993-23* |
Comply |
This resin has exceptional chemical resistance as well as moisture & immersion handling capability.
Please see full TDS here https://dm.henkel-dam.com/is/content/henkel/Loctite-3D-IND405-HDT50-High-Elongation
